Lifespan expires samples before reliable retransmission finishes
Rule 33 · applies to the publisher · Back to all rules
Breaks a guarantee. A lost sample expires before its retransmission arrives, so reliability cannot recover it.
If you set Reliability = RELIABLE together with Lifespan shorter than one publish period plus a round-trip
Breaks a guarantee
- Settings involved: Lifespan and Reliability
- What QoS Guard checks:
[RELIABLE] ∧ [LFSPAN.duration < PP + 2×RTT]
Example
Lifespan 30 ms with a 20 ms period and 50 ms RTT. Retransmitted samples arrive after they have already expired.
How to fix it
Set Lifespan longer than PP + 2 x RTT so retransmitted samples are still valid on arrival.
Why this rule is flagged
What the DDS specification says
The DDS specification does not settle this case on its own, so the rule rests on direct measurement.
What the engine source code shows
The behavior here does not depend on a specific engine's implementation, so the rule follows from the measurements.
What the measurements show
| Item | Value |
|---|---|
| Dataset | Download CSV |
| Fixed QoS setting | RELIAB = RELIABLE |
| Tested variable | LIFESPAN.duration |
| Tested values | LIFESPAN.duration ∈ {33 ms, 55 ms, 88 ms, 110 ms, 138 ms, 165 ms, 220 ms} |
| Rule boundary | PP + 2 × RTT = 10 ms + 2 × 50 ms = 110 ms |
| Rule-relevant case | LIFESPAN.duration < PP + 2 × RTT, i.e., LIFESPAN.duration ∈ {33 ms, 55 ms, 88 ms} |
| Tested engines / versions | Fast DDS 2.14.6 (Jazzy), Cyclone DDS 0.10.5 |
| Network setting | RTT = 50 ms, loss ∈ {0%, 20%}, PP = 10 ms, message size = 1024 B |
Measurement result
The heatmap shows average delivery ratio across tested LIFESPAN.duration values, with 110 ms marking the PP + 2 × RTT boundary.
